Three chamber system used for accomplishing of outside construction elements which require thermal insulation: windfalls, shop windows, balcony windows and doors. Three chamber construction improves system functionality and encourages investors to use Ponzio PT 60. Thanks to additional chamber causes higher stiffness, great dimension constructions can be accomplished in PT 60 system.
Characteristics of system
- precise relation to other Ponzio systems
- possibility of facing window sashes (one plane outside)
- fillings: 8-48 mm
- use of modern two components EPDM gaskets
- possibility of bending profiles
- many ways of accomplishing corner connections: torsion, studding or kneading
aluminium profiles
EN AV-6060 according to PN-EN 573-3/ T66 according to PN-EN 515 Al Mg Si 0,5 F22 according to DIN 1725 T1, DIN 17615 T1
fillings
single or packet window panels with any kind of glass or opaque panels
surface finishing
powder coating with polyester on chromate undercoater accoording to Qualicoat standards, any RAL colour at choice; anodized in colours: natutal aluminium, olive, champagne, gold, ?old gold?, brown - according to Qualanoad standards, lacquered for colour imitated wood
gaskets
synthetic caoutchouc EPDM according to DIN7863 and standard according to DIN7715 E2
connecting accessories
corner joints, screws, tap bolts, aluminium washers, inox or galvanized
furniture
renowned companies only: Savio, Erreti, Hautau, Geze, etc.
permissions and quality certificates
Compatibility certificate : 2 class of antiburglary according to PN-ENV 1627.
Type tests according PN-EN 14351
